What is SYNTEPORE™?

A diesel-fuel filtration architecture for primary and secondary particulate control.

How does SYNTEPORE™ work?

Staged synthetic media targets the particle population that threatens precision pumps and injector clearances.

What does SYNTEPORE™ protect?

Cleaner fuel helps maintain injector metering, pump durability, combustion quality, and fuel-system reliability.

What is SYNTEPORE™?

A diesel-fuel filtration architecture for primary and secondary particulate control.

How does SYNTEPORE™ work?

Staged synthetic media targets the particle population that threatens precision pumps and injector clearances.

What does SYNTEPORE™ protect?

Cleaner fuel helps maintain injector metering, pump durability, combustion quality, and fuel-system reliability.

Which technologies define ELIMFILTERS fuel cleanliness?

SYNTEPORE™, HYDROCORE™, and TURBOCORE™.

What is the difference between HYDROCORE™ and TURBOCORE™?

HYDROCORE™ is the fuel-water separation architecture for separator elements and assemblies, while TURBOCORE™ is dedicated to Turbine Series FH and FG systems.

Which failure modes are connected to SYNTEPORE™?

Particle Wear, Diesel Water Contamination

SYNTEPORE™ Proprietary Technology

Progressive multi-layer protection architecture intercepting sub-micron contamination before it reaches Common Rail injectors. The last line of defense for high-pressure fuel injection systems operating above 2,000 bar.

BARRIER RATING

4 MICRON

PROTECTION

ZERO MIGRATION

TARGET

INJECTOR DEFENSE

THE INJECTOR'S FINAL GUARDIAN.

Common Rail injection systems operate at pressures exceeding 2,000 bar. At this pressure, a contamination particle as small as 4 microns can score injector needle seats and destroy the precision tolerances that control injection timing and fuel atomization quality.

SYNTEPORE™ is engineered as the terminal protection layer between the fuel supply system and the injection circuit. Where pre-filters handle bulk contamination, SYNTEPORE™ eliminates the residual sub-micron fraction - the particles that conventional filtration misses and that HPCR systems cannot tolerate.

A Common Rail injector replacement costs $400-$1,200 per unit and requires specialized equipment. The contamination event that caused the failure typically occurred 50,000-100,000 km earlier - each particle that passed the terminal protection layer contributing incrementally to needle seat erosion that accelerated silently until the tolerance was exceeded.

SYNTEPORE™ - PRECISION INJECTOR GUARD ELEMENT

THREE PROGRESSIVE LAYERS. ABSOLUTE INJECTOR DEFENSE.

The outer protection layer intercepts particles from 40 microns down to 10 microns in a graduated capture architecture that distributes contamination load evenly across the filter surface. This zone prevents premature restriction at entry points and ensures full utilization of the protection matrix capacity across the service interval. Water droplets and gel contaminants are also intercepted at this stage before reaching the precision barrier.

40 micron

Progressive capture zone entry threshold

4 micron

PRECISION BARRIER

Absolute retention at terminal layer

PROGRESSIVE LAYERS

Load-distributed protection matrix

HPCR

INJECTION RATED

2,000+ bar system compatibility

STAGE 1

WATER INTERCEPT

Free and emulsified water capture

ZERO

BYPASS

No bypass under rated operating pressure

EXTENDED

SERVICE INTERVAL

Progressive loading extends service life

“Our HPCR injection system was generating one injector failure per 60,000 kilometers on average. With SYNTEPORE™ inline protection, we passed 180,000 kilometers on the test fleet with zero injection events. The sub-micron barrier is the difference.”
Technical Director · Commercial Fleet - Long-Haul Division

WHERE SYNTEPORE™ PROTECTS

SYNTEPORE™ is the designated precision protection element for any diesel system where fuel injection tolerances demand sub-4-micron cleanliness.

HEAVY TRANSPORT

A single Common Rail injector failure on a Euro VI long-haul truck removes the vehicle from service for a minimum of 24 hours for replacement and system flushing. HPCR systems in Euro IV-VI trucks are calibrated to tolerances below 5 microns - any particle that bypasses terminal filtration is operating inside the precision tolerance of the injector it reaches.

POWER GENERATION

Emergency standby generators start at full load demand with no warm-up period. There is no opportunity to divert the first fuel charge away from the injection system. If terminal fuel protection has degraded before the start event, the contamination event occurs at the moment of peak demand - when the genset cannot be taken offline.

AGRICULTURE

Precision agricultural machinery uses variable rate injection systems that modify fuel delivery in real time based on GPS-mapped field data. Contamination-induced injector drift corrupts injection map execution - causing under- or over-application that creates yield losses across entire field sections before the malfunction is diagnosed.

MINING

Remote extraction sites operate with supply chains measured in days or weeks per delivery cycle. An injector failure on a haul truck at a remote site means flying in parts at emergency freight rates or shutting the machine down until the next scheduled delivery. Either outcome costs more than any filtration investment.

CONSTRUCTION

Tier 4 Final emissions-compliant engines integrate injection system performance with SCR and DPF after-treatment. Injector deposits from contaminated fuel cause incomplete combustion that loads the DPF ahead of schedule - triggering active regeneration cycles that increase downtime and fuel consumption independently of the injection problem.

RAILWAY

Diesel locomotives take on fuel from maintenance depots and remote servicing points with varying quality assurance standards. A locomotive on a multi-day run may refuel from multiple sources. Terminal filtration protects the injection system against the worst-quality event in that sequence, not the average.

IDENTIFY YOUR SYNTEPORE™ ELEMENT
